Inverter

Model

SCAP-B-

51.2-100

SCAP-B-

51.2-200

SCAP-B-

51.2-300

SCAP-B-

51.2-400

Rated Power

5.5KW

6.2KW

AC Rated Voltage

230VAC

Rated Frequency

50/60Hz

Efficiency

≥98%

Transfer Time

10ms

Waveform

Pure sinusoidal wave

Battery Overvoltage

58.4V

Battery Undervoltage Alarm

45V

Constant Voltage Charge

58.4V

Float Voltage

56V

Max Charging Current

100A

120A

Communication Interface

RS232（Inverter) / RS485（BMS）

Dimension

60*18.3*36.5CM

AC Input

Nominal Voltage

230VAC

Voltage Range

90-280VAC

Rated Frequency

50/60Hz

Frequency Range

40-70Hz

Rated Current

30A

Max AC Current

60A

PV Input

Max Voltage

500V

Optimum Voltage

300-400V

Voltage Range

120V-500VDC

Max Power

5500W

8500W

Rated Capacity

5120Wh(100Ah）

10240Wh(200Ah）

15360Wh(300Ah）

20480Wh(400Ah）

Nominal Voltage

51.2V

Discharge Voltage Range

43.2V-58.4V

Standard Charing Current

50A

Max Charging Current

100A

120A

Battery

Max Discharging Current

100A

120A

Depth of Discharge

95%

Communication Interface

CAN / RS485

Cycle Life

≥6000，25±2℃，0.5C，EOL80%

Working Temperature Range

Charge：0℃-50℃；Discharge：-20℃-60℃

Storage Temperature

-10℃-60℃

Dimension

60*18.3*39CM
